Liquid Galaxy at The Ocean Conference


End Point had the privilege of participating in The Ocean Conference at the United Nations, hosted by the International Union for Conservation of Nature (IUCN), these past two weeks. The health of the oceans is critical, and The Ocean Conference, the first United Nations conference on this issue, presents a unique and invaluable opportunity for the world to reverse the precipitous decline of the health of the oceans and seas with concrete solutions.

A Liquid Galaxy was set up in a prominent area on the main floor of the United Nations. End Point created custom content for the Ocean Conference, using the Liquid Galaxy’s Content Management System. Visiting diplomats and government officials were able to experience this content - Liquid Galaxy’s interactive panoramic setup allows visitors to feel immersed in the different locations, with video and information spanning their periphery.

Liquid Galaxy content created for The Ocean Conference included:
-A study of the Catlin Seaview Survey and how the world's coral reefs are changing
-360 panoramic underwater videos
-All Mission Blue Ocean Hope Spots
-A guided tour of the Monaco Explorations 3 Year Expedition
-National Marine Sanctuaries around the United States

We were grateful to be able to create content for such a good cause, and hope to be able to do more good work for the IUCN and the UN! If you’d like to learn more, please visit our website or email ask@endpoint.com.

Successful First GEOINT Symposium for End Point Liquid Galaxy

This past week, End Point attended GEOINT Symposium to showcase Liquid Galaxy as an immersive panoramic GIS solution to GEOINT attendees and exhibitors alike.

At the show, we showcased Cesium integrating with ArcGIS and WMS, Google Earth, Street View, Sketchfab, Unity, and panoramic video. Using our Content Management System, we created content around these various features so visitors to our booth could take in the full spectrum of capabilities that the Liquid Galaxy provides.

Additionally, we were able to take data feeds for multiple other booths and display their content during the show! Our work served to show everyone at the conference that the Liquid Galaxy is a data-agnostic immersive platform that can handle any sort of data stream and offer data in a brilliant display. This can be used to show your large complex data sets in briefing rooms, conference rooms, or command centers.

Given the incredible draw of the Liquid Galaxy, the GEOINT team took special interest in our system and formally interviewed Ben Goldstein in front of the system to learn more! You can view the video of the interview here:



We look forward to developing the relationships we created at GEOINT, and hope to participate further in this great community moving forward. If you would like to learn more please visit our website or email ask@endpoint.com.







Amazon AWS upgrades to Postgres with Bucardo

Many of our clients at End Point are using the incredible Amazon Relational Database Service (RDS), which allows for quick setup and use of a database system. Despite minimizing many database administration tasks, some issues still exist, one of which is upgrading. Getting to a new version of Postgres is simple enough with RDS, but we've had clients use Bucardo to do the upgrade, rather than Amazon's built-in upgrade process. Some of you may be exclaiming "A trigger-based replication system just to upgrade?!"; while using it may seem unintuitive, there are some very good reasons to use Bucardo for your RDS upgrade:

Minimize application downtime

Many businesses are very sensitive to any database downtime, and upgrading your database to a new version always incurs that cost. Although RDS uses the ultra-fast pg_upgrade --links method, the whole upgrade process can take quite a while - or at least too long for the business to accept. Bucardo can reduce the application downtime from around seven minutes to ten seconds or less.

Upgrade more than one version at once

As of this writing (June 2017), RDS only allows upgrading of one major Postgres version at a time. Since pg_upgrade can easily handle upgrading older versions, this limitation will probably be fixed someday. Still, it means even more application downtime - to the tune of seven minutes for each major version. If you are going from 9.3 to 9.6 (via 9.4 and 9.5), that's at least 21 minutes of application downtime, with many unnecessary steps along the way. The total time for Bucardo to jump from 9.3 to 9.6 (or any major version to another one) is still under ten seconds.

Application testing with live data

The Bucardo upgrade process involves setting up a second RDS instance running the newer version, copying the data from the current RDS server, and then letting Bucardo replicate the changes as they come in. With this system, you can have two "live" databases you can point your applications to. With RDS, you must create a snapshot of your current RDS, upgrade *that*, and then point your application to the new (and frozen-in-time) database. Although this is still useful for testing your application against the newer version of the database, it is not as useful as having an automatically-updated version of the database.

Control and easy rollback

With Bucardo, the initial setup costs, and the overhead of using triggers on your production database, is balanced a bit by ensuring you have complete control over the upgrade process. The migration can happen when you want, at a pace you want, and can even happen in stages as you point some of the applications in your stack to the new version, while keeping some pointed at the old. And rolling back is as simple as pointing apps back at the older version. You could even set up Bucardo as "master-master", such that both new and old versions can write data at the same time (although this step is rarely necessary).

Database bloat removal

Although the pg_upgrade program that Amazon RDS uses for upgrading is extraordinarily fast and efficient, the data files are seldom, if ever, changed at all, and table and index bloat is never removed. On the other hand, an upgrade system using Bucardo creates the tables from scratch on the new database, and thus completely removes all historical bloat. (Indeed, one time a client thought something had gone wrong, as the new version's total database size had shrunk radically - but it was simply removal of all table bloat!).

Statistics remain in place

The pg_upgrade program currently has a glaring flaw - no copying of the information in the pg_statistic table. Which means that although an Amazon RDS upgrade completes in about seven minutes, the performance will range somewhere from slightly slow to completely unusable, until all those statistics are regenerated on the new version via the ANALYZE command. How long this can take depends on a number of factors, but in general, the larger your database, the longer it will take - a database-wide analyze can take hours on very large databases. As mentioned above, upgrading via Bucardo relies on COPYing the data to a fresh copy of the table. Although the statistics also need to be created when using Bucardo, the time cost for this does NOT apply to the upgrade time, as it can be done any time earlier, making the effective cost of generating statistics zero.

Upgrading RDS the Amazon way

Having said all that, the native upgrade system for RDS is very simple and fast. If the drawbacks above do not apply to you - or can be suffered with minimal business pain - then this way should always be the upgrade approach to use. Here is a quick walk through of how an Amazon RDS upgrade is done.

For this example, we will create a new Amazon RDS instance. The creation is amazingly simple: just log into aws.amazon.com, choose RDS, choose PostgreSQL (always the best choice!), and then fill in a few details, such as preferred version, server size, etc. The "DB Engine Version" was set as PostgreSQL 9.3.16-R1", the "DB Instance Class" as db.t2.small -- 1 vCPU, 2 GiB RAM, and "Multi-AZ Deployment" as no. All other choices are the default. To finish up this section of the setup, "DB Instance Identifier" was set to gregtest, the "Master Username" to greg, and the "Master Password" to b5fc93f818a3a8065c3b25b5e45fec19

Clicking on "Next Step" brings up more options, but the only one that needs to change is to specify the "Database Name" as gtest. Finally, the "Launch DB Instance" button. The new database is on the way! Select "View your DB Instance" and then keep reloading until the "Status" changes to Active.

Once the instance is running, you will be shown a connection string that looks like this: gregtest.zqsvirfhzvg.us-east-1.rds.amazonaws.com:5432. That standard port is not a problem, but who wants to ever type that hostname out, or even have to look at it? The pg_service.conf file comes to the rescue with this new entry inside the ~/.pg_service.conf file:

[gtest]
host=gregtest.zqsvirfhzvg.us-east-1.rds.amazonaws.com
port=5432
dbname=gtest
user=greg
password=b5fc93f818a3a8065c3b25b5e45fec19
connect_timeout=10

Now we run a quick test to make sure psql is able to connect, and that the database is an Amazon RDS database:

$ psql service=gtest -Atc "show rds.superuser_variables"
session_replication_role

We want to use the pgbench program to add a little content to the database, just to give the upgrade process something to do. Unfortunately, we cannot simply feed the "service=gtest" line to the pgbench program, but a little environment variable craftiness gets the job done:

$ unset PGSERVICEFILE PGSERVICE PGHOST PGPORT PGUSER PGDATABASE
$ export PGSERVICEFILE=/home/greg/.pg_service.conf PGSERVICE=gtest
$ pgbench -i -s 4
NOTICE:  table "pgbench_history" does not exist, skipping
NOTICE:  table "pgbench_tellers" does not exist, skipping
NOTICE:  table "pgbench_accounts" does not exist, skipping
NOTICE:  table "pgbench_branches" does not exist, skipping
creating tables...
100000 of 400000 tuples (25%) done (elapsed 0.66 s, remaining 0.72 s)
200000 of 400000 tuples (50%) done (elapsed 1.69 s, remaining 0.78 s)
300000 of 400000 tuples (75%) done (elapsed 4.83 s, remaining 0.68 s)
400000 of 400000 tuples (100%) done (elapsed 7.84 s, remaining 0.00 s)
vacuum...
set primary keys...
done.

At 68MB in size, this is still not a big database - so let's create a large table, then create a bunch of databases, to make pg_upgrade work a little harder:

## Make the whole database 1707 MB:
$ psql service=gtest -c "CREATE TABLE extra AS SELECT * FROM pgbench_accounts"
SELECT 400000
$ for i in {1..5}; do psql service=gtest -qc "INSERT INTO extra SELECT * FROM extra"; done

## Make the whole cluster about 17 GB:
$ for i in {1..9}; do psql service=gtest -qc "CREATE DATABASE gtest$i TEMPLATE gtest" ; done
$ psql service=gtest -c "SELECT pg_size_pretty(sum(pg_database_size(oid))) FROM pg_database WHERE datname ~ 'gtest'"
17 GB

To start the upgrade, we log into the AWS console, and choose "Instance Actions", then "Modify". Our only choices for instances are "9.4.9" and "9.4.11", plus some older revisions in the 9.3 branch. Why anything other than the latest revision in the next major branch (i.e. 9.4.11) is shown, I have no idea! Choose 9.4.11, scroll down to the bottom, choose "Apply Immediately", then "Continue", then "Modify DB Instance". The upgrade has begun!

How long will it take? All one can do is keep refreshing to see when your new database is ready. As mentioned above, 7 minutes and 30 seconds is the total time. The logs show how things break down:

11:52:43 DB instance shutdown
11:55:06 Backing up DB instance
11:56:12 DB instance shutdown
11:58:42 The parameter max_wal_senders was set to a value incompatible with replication. It has been adjusted from 5 to 10.
11:59:56 DB instance restarted
12:00:18 Updated to use DBParameterGroup default.postgres9.4

How much of that time is spent on upgrading though? Surprisingly little. We can do a quick local test to see how long the same database takes to upgrade from 9.3 to 9.4 using pg_upgrade --links: 20 seconds! Ideally Amazon will improve upon the total downtime at some point.

Upgrading RDS with Bucardo

As an asynchronous, trigger-based replication system, Bucardo is perfect for situations like this where you need to temporarily sync up two concurrent versions of Postgres. The basic process is to create a new Amazon RDS instance of your new Postgres version (e.g. 9.6), install the Bucardo program on a cheap EC2 box, and then have Bucardo replicate from the old Postgres version (e.g. 9.3) to the new one. Once both instances are in sync, just point your application to the new version and shut the old one down. One way to perform the upgrade is detailed below.

Some of the steps are simplified, but the overall process is intact. First, find a temporary box for Bucardo to run on. It doesn't have to be powerful, or have much disk space, but as network connectivity is important, using an EC2 box is recommended. Install Postgres (9.6 or better, because of pg_dump) and Bucardo (latest or HEAD recommended), then put your old and new RDS databases into your pg_service.conf file as "rds93" and "rds96" to keep things simple.

The next step is to make a copy of the database on the new Postgres 9.6 RDS database. We want the bare minimum schema here: no data, no triggers, no indexes, etc. Luckily, this is simple using pg_dump:

$ pg_dump service=rds93 --section=pre-data | psql -q service=rds96

From this point forward, no DDL should be run on the old server. We take a snapshot of the post-data items right away and save it to a file for later:

$ pg_dump service=rds93 --section=post-data -f rds.postdata.pg

Time to get Bucardo ready. Recall that Bucardo can only replicate tables that have a primary key or unique index. But if those tables are small enough, you can simply copy them over at the final point of migration later.

$ bucardo install
$ bucardo add db A dbservice=rds93
$ bucardo add db B dbservice=rds96
## Create a sync and name it 'migrate_rds':
$ bucardo add sync migrate_rds tables=all dbs=A,B

That's it! The current database will now have triggers that are recording any changes made, so we may safely do a bulk copy to the new database. This step might take a very long time, but that's not a problem.

$ pg_dump service=rds93 --section=data | psql -q service=rds96

Before we create the indexes on the new server, we start the Bucardo sync to copy over any rows that were changed while the pg_dump was going on. After that, the indexes, primary keys, and other items can be created:

$ bucardo start
$ tail -f log.bucardo ## Wait until the sync finishes once
$ bucardo stop
$ psql service=rds96 -q -f rds.postdata.pg

For the final migration, we simply stop anything from writing to the 9.3 database, have Bucardo perform a final sync of any changed rows, and then point your application to the 9.6 database. The whole process can happen very quickly: well under a minute for most cases.

Upgrading major Postgres versions is never a trivial task, but both Bucardo and pg_upgrade allow it to be orders of magnitude faster and easier than the old method of using the pg_dump utility. Upgrading your Amazon AWS Postgres instance is fast and easy using the AWS pg_upgrade method, but it has limitations, so having Bucardo help out can be a very useful option.

Series Digital joins End Point!

End Point has the pleasure to announce some very big news!

After an amicable wooing period, End Point has purchased the software consulting company Series Digital, a NYC-based firm that designs and builds custom software solutions. Over the past decade, Series Digital has automated business processes, brought new ideas to market, and built large-scale dynamic infrastructure.

Series Digital website snapshotSeries Digital launched in 2006 in New York City. From the start, Series Digital managed large database installations for financial services clients such as Goldman Sachs, Merrill Lynch, and Citigroup. They also worked with startups including Drop.io, Byte, Mode Analytics, Domino, and Brewster.

These growth-focused, data-intensive businesses benefited from Series Digital’s expertise in scalable infrastructure, project management, and information security. Today, Series Digital supports clients across many major industry sectors and has focused its development efforts on the Microsoft .NET ecosystem. They have strong design and user experience expertise. Their client list is global.

The Series Digital team began working at End Point on April 3rd, 2017.

The CEO of Series Digital is Jonathan Blessing. He joins End Point’s leadership team as Director of Client Engagements. End Point has had a relationship with Jonathan since 2010, and looks forward with great anticipation to the role he will play expanding End Point’s consulting business.

To help support End Point’s expansion into .NET solutions, End Point has hired Dan Briones, a 25-year veteran of IT infrastructure engineering, to serve as Project and Team Manager for the Series Digital group. Dan started working with End Point at the end of March.

The End Point leadership team is very excited by the addition of Dan, Jonathan, and the rest of the talented Series Digital team: Jon Allen, Ed Huott, Dylan Wooters, Vasile Laur, Liz Flyntz, Andrew Grosser, William Yeack, and Ian Neilsen.

End Point’s reputation has been built upon its excellence in e-commerce, managed infrastructure, and database support. We are excited by the addition of Series Digital, which both deepens those abilities, and allows us to offer new services.

Talk to us to hear about the new ways we can help you!

Recognizing handwritten digits - a quick peek into the basics of machine learning

Previous in series:
In the previous two posts on machine learning, I presented a very basic introduction of an approach called "probabilistic graphical models". In this post I'd like to take a tour of some different techniques while creating code that will recognize handwritten digits.

The handwritten digits recognition is an interesting topic that has been explored for many years. It is now considered one of the best ways to start the journey into the world of machine learning.

Taking the Kaggle challenge

We'll take the "digits recognition" challenge as presented in Kaggle. It is an online platform with challenges for data scientists. Most of the challenges have their prizes expressed in real money to win. Some of them are there to help us out in our journey on learning data science techniques — so is the "digits recognition" contest.

The challenge

As explained on Kaggle:

MNIST ("Modified National Institute of Standards and Technology") is the de facto “hello world” dataset of computer vision.

The "digits recognition" challenge is one of the best ways to get acquainted with machine learning and computer vision. The so-called "MNIST" dataset consists of 70k images of handwritten digits - each one grayscaled and of a 28x28 size. The Kaggle challenge is about taking a subset of 42k of them along with labels (what actual number does the image show) and "training" the computer on that set. The next step is to take the rest 28k of images without the labels and "predict" which actual number they present.

Here's a short overview of how the digits in a set really look like (along with the numbers they represent):


I have to admit that for some of them I have a really hard time recognizing the actual numbers on my own :)

The general approach to supervised learning

Learning from labelled data is what is called "supervised learning". It's supervised because we're taking the computer by hand through the whole training data set and "teaching" it how the data that is linked with different labels "looks" like.

In all such scenarios we can express the data and labels as:
Y ~ X1, X2, X3, X4, ..., Xn
The Y is called a dependent variable while each Xn are independent variables. This formula holds both for classification problems as well as regressions.

Classification is when the dependent variable Y is so called categorical — taking values from a concrete set without a meaningful order. Regression is when the Y is not categorical — most often continuous.

In the digits recognition challenge we're faced with the classification task. The dependent variable takes values from the set:
Y = { 0, 1, 2, 3, 4, 5, 6, 7, 8, 9 }
I'm sure the question you might be asking yourself now is: what are the independent variables Xn? It turns out to be the crux of the whole problem to solve :)

The plan of attack

A good introduction to computer vision techniques is a book by J. R Parker - "Algorithms for Image Processing and Computer Vision". I encourage the reader to buy that book. I took some ideas from it while having fun with my own solution to the challenge.

The book outlines the ideas revolving around computing image profiles — for each side. For each row of pixels, a number representing the distance of the first pixel from the edge is computed. This way we're getting our first independent variables. To capture even more information about digit shapes, we'll also capture the differences between consecutive row values as well as their global maxima and minima. We'll also compute the width of the shape for each row.

Because the handwritten digits vary greatly in their thickness, we will first preprocess the images to detect so-called skeletons of the digit. The skeleton is an image representation where the thickness of the shape has been reduced to just one.

Having the image thinned will also allow us to capture some more info about the shapes. We will write an algorithm that walks the skeleton and records the direction change frequencies.

Once we'll have our set of independent variables Xn, we'll use a classification algorithm to first learn in a supervised way (using the provided labels) and then to predict the values of the test data set. Lastly we'll submit our predictions to Kaggle and see how well did we do.

Having fun with languages

In the data science world, the lingua franca still remains to be the R programming language. In the last years Python has also came close in popularity and nowadays we can say it's the duo of R and Python that rule the data science world (not counting high performance code written e. g. in C++ in production systems).

Lately a new language designed with data scientists in mind has emerged - Julia. It's a language with characteristics of both dynamically typed scripting languages as well as strictly typed compiled ones. It compiles its code into efficient native binary via LLVM — but it's using it in a JIT fashion - inferring the types when needed on the go.

While having fun with the Kaggle challenge I'll use Julia and Python for the so called feature extraction phase (the one in which we're computing information about our Xn variables). I'll then turn towards R for doing the classification itself. Note that I might use any of those languages at each step getting very similar results. The purpose of this series of articles is to be a bird eye fun overview so I decided that this way will be much more interesting.

Feature Extraction

The end result of this phase is the data frame saved as a CSV file so that we'll be able to load it in R and do the classification.

First let's define the general function in Julia that takes the name of the input CSV file and returns a data frame with features of given images extracted into columns:
using DataFrames

function get_data(name :: String, include_label = true)
  println("Loading CSV file into a data frame...")
  table = readtable(string(name, ".csv"))
  extract(table, include_label)
end
Now the extract function looks like the following:
"""
Extracts the features from the dataframe. Puts them into
separate columns and removes all other columns except the
labels.

The features:

* Left and right profiles (after fitting into the same sized rect):
  * Min
  * Max
  * Width[y]
  * Diff[y]
* Paths:
  * Frequencies of movement directions
  * Simplified directions:
    * Frequencies of 3 element simplified paths
"""
function extract(frame :: DataFrame, include_label = true)
  println("Reshaping data...")

  function to_image(flat :: Array{Float64}) :: Array{Float64}
    dim      = Base.isqrt(length(flat))
    reshape(flat, (dim, dim))'
  end

  from = include_label ? 2 : 1
  frame[:pixels] = map((i) -> convert(Array{Float64}, frame[i, from:end]) |> to_image, 1:size(frame, 1))
  images = frame[:, :pixels] ./ 255
  data = Array{Array{Float64}}(length(images))

  @showprogress 1 "Computing features..." for i in 1:length(images)
    features = pixels_to_features(images[i])
    data[i] = features_to_row(features)
  end
  start_column = include_label ? [:label] : []
  columns = vcat(start_column, features_columns(images[1]))

  result = DataFrame()
  for c in columns
    result[c] = []
  end

  for i in 1:length(data)
    if include_label
      push!(result, vcat(frame[i, :label], data[i]))
    else
      push!(result, vcat([],               data[i]))
    end
  end

  result
end
A few nice things to notice here about Julia itself are:
  • The function documentation is written in Markdown
  • We can nest functions inside other functions
  • The language is statically and strongly typed
  • Types can be inferred from the context
  • It is often desirable to provide the concrete types to improve performance (but that an advanced Julia related topic)
  • Arrays are indexed from 1
  • There's the nice |> operator found e. g. In Elixir (which I absolutely love)
The above code converts the images to be arrays of Float64 and converts the values to be within 0 and 1 (instead of 0..255 originally).

A thing to notice is that in Julia we can vectorize operations easily and we're using this fact to tersely convert our number:
images = frame[:, :pixels] ./ 255
We are referencing the pixels_to_features function which we define as:
"""
Returns ImageFeatures struct for the image pixels
given as an argument
"""
function pixels_to_features(image :: Array{Float64})
  dim      = Base.isqrt(length(image))
  skeleton = compute_skeleton(image)
  bounds   = compute_bounds(skeleton)
  resized  = compute_resized(skeleton, bounds, (dim, dim))
  left     = compute_profile(resized, :left)
  right    = compute_profile(resized, :right)
  width_min, width_max, width_at = compute_widths(left, right, image)
  frequencies, simples = compute_transitions(skeleton)

  ImageStats(dim, left, right, width_min, width_max, width_at, frequencies, simples)
end
This in turn uses the ImageStats structure:
immutable ImageStats
  image_dim             :: Int64
  left                  :: ProfileStats
  right                 :: ProfileStats
  width_min             :: Int64
  width_max             :: Int64
  width_at              :: Array{Int64}
  direction_frequencies :: Array{Float64}

  # The following adds information about transitions
  # in 2 element simplified paths:
  simple_direction_frequencies :: Array{Float64}
end

immutable ProfileStats
  min :: Int64
  max :: Int64
  at  :: Array{Int64}
  diff :: Array{Int64}
end
The pixels_to_features function first gets the skeleton of the digit shape as an image and then uses other functions passing that skeleton to them. The function returning the skeleton utilizes the fact that in Julia it's trivially easy to use Python libraries. Here's its definition:
using PyCall

@pyimport skimage.morphology as cv

"""
Thin the number in the image by computing the skeleton
"""
function compute_skeleton(number_image :: Array{Float64}) :: Array{Float64}
  convert(Array{Float64}, cv.skeletonize_3d(number_image))
end
It uses the scikit-image library's function skeletonize3d by using the @pyimport macro and using the function as if it was just a regular Julia code.

Next the code crops the digit itself from the 28x28 image and resizes it back to 28x28 so that the edges of the shape always "touch" the edges of the image. For this we need the function that returns the bounds of the shape so that it's easy to do the cropping:
function compute_bounds(number_image :: Array{Float64}) :: Bounds
  rows = size(number_image, 1)
  cols = size(number_image, 2)

  saw_top = false
  saw_bottom = false

  top = 1
  bottom = rows
  left = cols
  right = 1

  for y = 1:rows
    saw_left = false
    row_sum = 0

    for x = 1:cols
      row_sum += number_image[y, x]

      if !saw_top && number_image[y, x] > 0
        saw_top = true
        top = y
      end

      if !saw_left && number_image[y, x] > 0 && x < left
        saw_left = true
        left = x
      end

      if saw_top && !saw_bottom && x == cols && row_sum == 0
        saw_bottom = true
        bottom = y - 1
      end

      if number_image[y, x] > 0 && x > right
        right = x
      end
    end
  end
  Bounds(top, right, bottom, left)
end
Resizing the image is pretty straight-forward:
using Images

function compute_resized(image :: Array{Float64}, bounds :: Bounds, dims :: Tuple{Int64, Int64}) :: Array{Float64}
  cropped = image[bounds.left:bounds.right, bounds.top:bounds.bottom]
  imresize(cropped, dims)
end
Next, we need to compute the profile stats as described in our plan of attack:
function compute_profile(image :: Array{Float64}, side :: Symbol) :: ProfileStats
  @assert side == :left || side == :right

  rows = size(image, 1)
  cols = size(image, 2)

  columns = side == :left ? collect(1:cols) : (collect(1:cols) |> reverse)
  at = zeros(Int64, rows)
  diff = zeros(Int64, rows)
  min = rows
  max = 0

  min_val = cols
  max_val = 0

  for y = 1:rows
    for x = columns
      if image[y, x] > 0
        at[y] = side == :left ? x : cols - x + 1

        if at[y] < min_val
          min_val = at[y]
          min = y
        end

        if at[y] > max_val
          max_val = at[y]
          max = y
        end
        break
      end
    end
    if y == 1
      diff[y] = at[y]
    else
      diff[y] = at[y] - at[y - 1]
    end
  end

  ProfileStats(min, max, at, diff)
end
The widths of shapes can be computed with the following:
function compute_widths(left :: ProfileStats, right :: ProfileStats, image :: Array{Float64}) :: Tuple{Int64, Int64, Array{Int64}}
  image_width = size(image, 2)
  min_width = image_width
  max_width = 0
  width_ats = length(left.at) |> zeros

  for row in 1:length(left.at)
    width_ats[row] = image_width - (left.at[row] - 1) - (right.at[row] - 1)

    if width_ats[row] < min_width
      min_width = width_ats[row]
    end

    if width_ats[row] > max_width
      max_width = width_ats[row]
    end
  end

  (min_width, max_width, width_ats)
end
And lastly, the transitions:
function compute_transitions(image :: Image) :: Tuple{Array{Float64}, Array{Float64}}
  history = zeros((size(image,1), size(image,2)))

  function next_point() :: Nullable{Point}
    point = Nullable()

    for row in 1:size(image, 1) |> reverse
      for col in 1:size(image, 2) |> reverse
        if image[row, col] > 0.0 && history[row, col] == 0.0
          point = Nullable((row, col))
          history[row, col] = 1.0

          return point
        end
      end
    end
  end

  function next_point(point :: Nullable{Point}) :: Tuple{Nullable{Point}, Int64}
    result = Nullable()
    trans = 0

    function direction_to_moves(direction :: Int64) :: Tuple{Int64, Int64}
      # for frequencies:
      # 8 1 2
      # 7 - 3
      # 6 5 4
      [
       ( -1,  0 ),
       ( -1,  1 ),
       (  0,  1 ),
       (  1,  1 ),
       (  1,  0 ),
       (  1, -1 ),
       (  0, -1 ),
       ( -1, -1 ),
      ][direction]
    end

    function peek_point(direction :: Int64) :: Nullable{Point}
      actual_current = get(point)

      row_move, col_move = direction_to_moves(direction)

      new_row = actual_current[1] + row_move
      new_col = actual_current[2] + col_move

      if new_row <= size(image, 1) && new_col <= size(image, 2) &&
         new_row >= 1 && new_col >= 1
        return Nullable((new_row, new_col))
      else
        return Nullable()
      end
    end

    for direction in 1:8
      peeked = peek_point(direction)

      if !isnull(peeked)
        actual = get(peeked)
        if image[actual[1], actual[2]] > 0.0 && history[actual[1], actual[2]] == 0.0
          result = peeked
          history[actual[1], actual[2]] = 1
          trans = direction
          break
        end
      end
    end

    ( result, trans )
  end

  function trans_to_simples(transition :: Int64) :: Array{Int64}
    # for frequencies:
    # 8 1 2
    # 7 - 3
    # 6 5 4

    # for simples:
    # - 1 -
    # 4 - 2
    # - 3 -
    [
      [ 1 ],
      [ 1, 2 ],
      [ 2 ],
      [ 2, 3 ],
      [ 3 ],
      [ 3, 4 ],
      [ 4 ],
      [ 1, 4 ]
    ][transition]
  end

  transitions     = zeros(8)
  simples         = zeros(16)
  last_simples    = [ ]
  point           = next_point()
  num_transitions = .0
  ind(r, c) = (c - 1)*4 + r

  while !isnull(point)
    point, trans = next_point(point)

    if isnull(point)
      point = next_point()
    else
      current_simples = trans_to_simples(trans)
      transitions[trans] += 1
      for simple in current_simples
        for last_simple in last_simples
          simples[ind(last_simple, simple)] +=1
        end
      end
      last_simples = current_simples
      num_transitions += 1.0
    end
  end

  (transitions ./ num_transitions, simples ./ num_transitions)
end
All those gathered features can be turned into rows with:
function features_to_row(features :: ImageStats)
  lefts       = [ features.left.min,  features.left.max  ]
  rights      = [ features.right.min, features.right.max ]

  left_ats    = [ features.left.at[i]  for i in 1:features.image_dim ]
  left_diffs  = [ features.left.diff[i]  for i in 1:features.image_dim ]
  right_ats   = [ features.right.at[i] for i in 1:features.image_dim ]
  right_diffs = [ features.right.diff[i]  for i in 1:features.image_dim ]
  frequencies = features.direction_frequencies
  simples     = features.simple_direction_frequencies

  vcat(lefts, left_ats, left_diffs, rights, right_ats, right_diffs, frequencies, simples)
end
Similarly we can construct the column names with:
function features_columns(image :: Array{Float64})
  image_dim   = Base.isqrt(length(image))

  lefts       = [ :left_min,  :left_max  ]
  rights      = [ :right_min, :right_max ]

  left_ats    = [ Symbol("left_at_",  i) for i in 1:image_dim ]
  left_diffs  = [ Symbol("left_diff_",  i) for i in 1:image_dim ]
  right_ats   = [ Symbol("right_at_", i) for i in 1:image_dim ]
  right_diffs = [ Symbol("right_diff_", i) for i in 1:image_dim ]
  frequencies = [ Symbol("direction_freq_", i)   for i in 1:8 ]
  simples     = [ Symbol("simple_trans_", i)   for i in 1:4^2 ]

  vcat(lefts, left_ats, left_diffs, rights, right_ats, right_diffs, frequencies, simples)
end
The data frame constructed with the get_data function can be easily dumped into the CSV file with the writeable function from the DataFrames package.

You can notice that gathering / extracting features is a lot of work. All this was needed to be done because in this article we're focusing on the somewhat "classical" way of doing machine learning. You might have heard about algorithms existing that mimic how the human brain learns. We're not focusing on them here. This we will explore in some future article.

We use the mentioned writetable on data frames computed for both training and test datasets to store two files: processed_train.csv and processed_test.csv.

Choosing the model

For the task of classifying I decided to use the XGBoost library which is somewhat a hot new technology in the world of machine learning. It's an improvement over the so-called Random Forest algorithm. The reader can read more about XGBoost on its website: http://xgboost.readthedocs.io/.

Both random forest and xgboost revolve around the idea called ensemble learning. In this approach we're not getting just one learning model — the algorithm actually creates many variations of models and uses them to collectively come up with better results. This is as much as can be written as a short description as this article is already quite lengthy.

Training the model

The training and classification code in R is very simple. We first need to load the libraries that will allow us to load data as well as to build the classification model:
library(xgboost)
library(readr)
Loading the data into data frames is equally straight-forward:
processed_train <- read_csv("processed_train.csv")
processed_test <- read_csv("processed_test.csv")
We then move on to preparing the vector of labels for each row as well as the matrix of features:
labels = processed_train$label
features = processed_train[, 2:141]
features = scale(features)
features = as.matrix(features)

The train-test split

When working with models, one of the ways of evaluating their performance is to split the data into so-called train and test sets. We train the model on one set and then we predict the values from the test set. We then calculate the accuracy of predicted values as the ratio between the number of correct predictions and the number of all observations.

Because Kaggle provides the test set without labels, for the sake of evaluating the model's performance without the need to submit the results, we'll split our Kaggle-training set into local train and test ones. We'll use the amazing caret library which provides a wealth of tools for doing machine learning:
library(caret)

index <- createDataPartition(processed_train$label, p = .8,
                             list = FALSE,
                             times = 1)

train_labels <- labels[index]
train_features <- features[index,]

test_labels <- labels[-index]
test_features <- features[-index,]
The above code splits the set uniformly based on the labels so that the train set is approximately 80% in size of the whole data set.

Using XGBoost as the classification model

We can now make our data digestible by the XGBoost library:
train <- xgb.DMatrix(as.matrix(train_features), label = train_labels)
test  <- xgb.DMatrix(as.matrix(test_features),  label = test_labels)
The next step is to make the XGBoost learn from our data. The actual parameters and their explanations are beyond the scope of this overview article, but the reader can look them up on the XGBoost pages:
model <- xgboost(train,
                 max_depth = 16,
                 nrounds = 600,
                 eta = 0.2,
                 objective = "multi:softmax",
                 num_class = 10)
It's critically important to pass the objective as "multi:softmax" and num_class as 10.

Simple performance evaluation with confusion matrix

After waiting a while (couple of minutes) for the last batch of code to finish computing, we now have the classification model ready to be used. Let's use it to predict the labels from our test set:
predicted = predict(model, test)
This returns the vector of predicted values. We'd now like to check how well our model predicts the values. One of the easiest ways is to use the so-called confusion matrix.

As per Wikipedia, confusion matrix is simply:

(...) also known as an error matrix, is a specific table layout that allows visualization of the performance of an algorithm, typically a supervised learning one (in unsupervised learning it is usually called a matching matrix). Each column of the matrix represents the instances in a predicted class while each row represents the instances in an actual class (or vice versa). The name stems from the fact that it makes it easy to see if the system is confusing two classes (i.e. commonly mislabelling one as another).

The caret library provides a very easy to use function for examining the confusion matrix and statistics derived from it:
confusionMatrix(data=predicted, reference=labels)
The function returns an R list that gets pretty printed to the R console. In our case it looks like the following:
Confusion Matrix and Statistics

          Reference
Prediction   0   1   2   3   4   5   6   7   8   9
         0 819   0   3   3   1   1   2   1  10   5
         1   0 923   0   4   5   1   5   3   4   5
         2   4   2 766  26   2   6   8  12   5   0
         3   2   0  15 799   0  22   2   8   0   8
         4   5   2   1   0 761   1   0  15   4  19
         5   1   3   0  13   2 719   3   0   9   6
         6   5   3   4   1   6   5 790   0  16   2
         7   1   7  12   9   2   3   1 813   4  16
         8   6   2   4   7   8  11   8   5 767  10
         9   5   2   1  13  22   6   1  14  14 746

Overall Statistics

               Accuracy : 0.9411
                 95% CI : (0.9358, 0.946)
    No Information Rate : 0.1124
    P-Value [Acc > NIR] : < 2.2e-16

                  Kappa : 0.9345
 Mcnemar's Test P-Value : NA

(...)
Each column in the matrix represents actual labels while rows represent what our algorithms predicted this value to be. There's also the accuracy rate printed for us and in this case it equals 0.9411. This means that our code was able to predict correct values of handwritten digits for 94.11% of observations.

Submitting the results

We got 0.9411 of an accuracy rate for our local test set and it turned out to be very close to the one we got against the test set coming from Kaggle. After predicting the competition values and submitting them, the accuracy rate computed by Kaggle was 0.94357. That's quite okay given the fact that we're not using here any of the new and fancy techniques.

Also, we haven't done any parameter tuning which could surely improve the overall accuracy. We could also revisit the code from the features extraction phase. One improvement I can think of would be to first crop and resize back - and only then compute the skeleton which might preserve more information about the shape. We could also use the confusion matrix and taking the number that was being confused the most, look at the real images that we failed to recognize. This could lead us to conclusions about improvements to our feature extraction code. There's always a way to extract more information.

Nowadays, Kagglers from around the world were successfully using advanced techniques like Convolutional Neural Networks getting accuracy scores close to 0.999. Those live in somewhat different branch of the machine learning world though. Using this type of neural networks we don't need to do the feature extraction on our own. The algorithm includes the step that automatically gathers features that it later on feeds into the network itself. We will take a look at them in some of the future articles.

See also

infoShare 2017 - JavaScript, JavaScript everywhere

The last week was really interesting for me. I attended the infoShare 2017, the biggest tech conference in central-eastern Europe. The agenda was impressive, but that’s not everything. There was a startup competition going on and really, I’m totally impressed.

infoShare in numbers:

  • 5500 attendees
  • 133 speakers
  • 250 startups
  • 122 hours of speeches
  • 12 side events
Let’s go through each speech I was attending.

Day 1

Why Fast Matters by Harry Roberts from csswizardry.com

Harry tried to convince us that performance is important.


Great speech, showing that it’s an interesting problem not only from a financial point of view. You must see it, link to his presentation: https://speakerdeck.com/csswizardry/why-fast-matters

Dirty Little Tricks From The Dark Corners of Front-End by Vitaly Friedman from smashingmagazine.com

It was magic! I work a lot with CSS, but this speech showed me some new ideas and reminded me that the simplest solution is maybe not the best solution usually and that we should reuse CSS between components as much as possible.

Keep it DRY!

One of these tricks is a quantity query CSS selector. It’s a pretty complex selector that can apply your styles to elements based on the number of siblings. (http://quantityqueries.com/)

The Art of Debugging (browsers) by Remy Sharp

It was great to see some other developer and see his workflow during debugging. I usually work from home and it’s not easy to do it in my case.

Remy is a very experienced JavaScript developer and showed us his skills and tricks, especially interesting Chrome developer console integration.

I always thought that using the developer console for programming is not the best idea, maybe it’s not? It looked pretty neat.

Desktop Apps with JavaScript by Felix Rieseberg from Slack

Felix from Slack presented and show the power of desktop hybrid apps. He used a framework called Electron. Using Electron you can build native, cross-system desktop apps using HTML, JavaScript and CSS. I don’t think that it’s the best approach for more complex applications and probably takes more system memory than native-native applications, but for simpler apps it can a way to go!

Github uses it to build their desktop app, so maybe it’s not so slow? :)

RxJava in existing projects by Tomasz Nurkiewicz from Allegro

Tomasz Nurkiewicz from Allegro showed us his high programming skills and provided some practical RxJava examples. RxJava is a library for composing asynchronous and event-based programs using observable sequences for the Java VM.

Definitely something to read about.

Day 2

What does a production ready Kubernetes application look like? by Carter Morgan from Google

Carter Morgan from Google showed us practical uses of Kubernetes.

Kubernetes is an open-source system for automating deployment, scaling and management of containerized applications. It was originally designed by Google developers and I think that they really want to popularize it. It looked that Kubernetes has a low learning curve, but devops agents I spoke after the presentation were sceptical, saying that if you know how to use Docker Swarm then you don’t really need Kubernetes.

Vue.js and Service Workers become Realtime by Blake Newman from Sainsbury's

Blake Newman is a JavaScript developer, member of the core Vue.js (trending, hot JavaScript framework) team. He explained how to use Vue.js with service workers.

The service workers are scripts that your browser runs in the background. Nice to see how it fits together, even though it’s not yet supported by every popular browser.





Listen to your application and sleep by Gianluca Arbezzano from InfluxData

Gianluca showed us his modern and flexible monitoring stack. Great tips and mostly discussing and recommending InfluxDB and Telegraf, we use it a lot in End Point.

He was right that it’s easy to configure, open-source and really useful. Great speech!

Summary

Amazing two days. All the presentations will be available on Youtube soon: https://www.youtube.com/user/infoSharePL/videos.

I can fully recommend this conference, see you next time!

Drupal - rapid development

Here at End Point, we had the pleasure to be a part of multiple Drupal 6, 7 and 8 projects. Most of our clients wanted to use the latest Drupal version, to have a long term support, stable platform.

A few years ago, I already had big experience with PHP itself and other, various PHP frameworks like WordPress, Joomla! or TYPO3. I was happy to use all of them, but then one of our clients asked us for a simple Drupal 6 task. That’s how I started my Drupal journey which continues until now.

To be honest, I had a difficult start, it was different, new and pretty inscrutable for me. After a few days of reading documentation and playing with the system I was ready to do some simple work. Here, I wanted to share my thoughts about Drupal and tell you why I LOVE! it.

Low learning curve

It took, of course, a few months until I was ready to build something more complex, but it really takes a few days only to be ready for simple development. It’s not only about Drupal, but also PHP, it’s much cheaper to maintain and extend a project. Maybe it’s not so important with smaller projects, but definitely important for massive code bases. Programmers can jump in and start being productive really quick.

Great documentation

Drupal documentation is well structured and constantly developed, usually you can find what you need within a few minutes. It’s critical and must have for any other framework and not so common unfortunately.

Big community

The Drupal community is one of the biggest IT communities I have ever encountered. They extend, fix and document the Drupal core regularly. Most of them have their other jobs and work on this project just for fun and with passion.

It’s free

It’s an open source project, that’s one of the biggest pros here. You can get it for free, you can get support for free, you can join the community for free too (:)).

Modules

On the official Drupal website you can find tons of free plugins/modules. It’s a time and money saver, you don’t need to reinvent the wheel for every new widget on your website and focus on fireworks.

Usually you can just go there and find a proper component. E-commerce shop? Slideshow? Online classifieds website? No problem! It’s all there.

PHP7 support

I can often hear from other developers that PHP is slow, well, it’s not the Road Runner, but come on, unless you are Facebook (and I think that they, correct me if I’m wrong, still use PHP :)) it’s just OK to use PHP.

Drupal fully supports PHP7.

With PHP7 it’s much faster, better and safer. To learn more: https://pages.zend.com/rs/zendtechnologies/images/PHP7-Performance%20Infographic.pdf.

In the infographic you can see that PHP7 is much faster than Ruby, Perl and Python when you try to render a Mandelbrot fractal. In general, you definitely can’t say that PHP is slow, same as Drupal.

REST API support

Drupal has the built in, ready to use API system. In a few moments you can spawn a new API endpoint for you application. You don’t need to implement a whole API by yourself, I did it a few times in multiple languages, believe me, it’s problematic.

Perfect for a backend system

Drupal is a perfect candidate for a backend system. Let’s imagine that you want to build a beautiful, mobile application. You want to let editors, other people to edit content. You want to grab this content through the API. It’s easy as pie with Drupal.

Drupal’s web interface is stable and easy to use.

Power of taxonomies

Taxonomies are, really basically, just dictionaries. The best thing about taxonomies is that you don’t need to touch code to play with them.

Let’s say that on your website you want to create a list of states in the USA. Using most of the frameworks you need to ask your developer/technical person to do so. With taxonomies you just need a few clicks and that’s it, you can put in on your website. That’s sweet, not only for non technical person, but for us, developers as well. Again, you can focus on actually making the website attractive, rather than spending time on things that can be automated.

Summary

Of course, Drupal is not perfect, but it’s undeniably a great tool. Mobile application, single page application, corporate website - there are no limits for this content management system. And actually, it is, in my opinion, the best tool to manage your content and it does not mean that you need to use Drupal to present it. You can create a mobile, ReactJS, AngularJS, VueJS application and combine it with Drupal easily.

I hope that you’ve had a good reading and wish to hear back from you! Thanks.
